UAZ 2206 AMC
Country Van SG

8-9 seats
An off-road mini­bus with a centra­lly loca­ted engi­ne which can tran­sport up to 9 people.

UAZ 2206 AMC
Country Van SG

8-9 seats
An off-road mini­bus with a centra­lly loca­ted engi­ne and idea­lly distri­buted weig­ht which can tran­sport up to 9 people in the most deman­ding terra­in.
An off-road mini­bus with a centra­lly loca­ted engi­ne and idea­lly distri­buted weig­ht which can tran­sport up to 9 people.

Description

Vehicle category
SG, expediční / SG, montážní
Drivetrain
4x4
Operating weight
1850-2475 kg
GVWR
405-1030 kg
Number of seats / doors
8 - 9 / 4
Clearance
210 mm
Wheelbase
2 300 mm
Front gauge
1 475 mm
Rear gauge
1 485 mm
Fuel tank capacity
77 L
Cargo space size
200 × 1 680 mm

The UAZ 2206 AMC Country Van SG is a special purpose vehicle offering 8-9 seats and representing unbeatable off-road performance in its class. It has an all metal closed body on a high torsion ladder frame. The suspension consist of two solid axles and four leaf springs. This setup guarantees a long lifespan of the whole chassis. Among further advantages is the minimal use of electronics, the simple design, reliability and low maintenance costs.

Starting from 23 669 €
Vehicles have valid approvals in CIS, EU and EEC countries.

Engines

Fuel
Petrol
Engine capacity
2 693 cm3
Output
83 kW / 4 250 rpm
Torque
213 Nm / 2 500 rpm
Fuel consumption
Benzín: 13,1-13,9, LPG 13,7-16,5 l/100km
CO2
Benzín 303-322, LPG 222-266 g/km
Technical Description
ZMZ 40911
ZMZ 40911

This modern spark-ignition 16V engine is equipped with BOSCH fuel injection.  It provides maximal output and torque in low revs, which implies its fundamental advantage in harsh off-road operation. During the on-road operation it offers swift moving offs and cultivated running. Its sufficient output and gear ratios enable problem-free motorway operation. This engine type is suitable for a modification to LPG fuel and can be diagnosed via OBD connector.

The modern 5-speed manual transmission makes this light off-road vehicle swift and also confortable during long on-road driving. A manually connectable 4x4 drive and 2-speed low range gearbox are essential during off-road driving. The centrally located engine causes ideal weight distribution to both axles and improves off-road capabilities in harsh terrain.

Equipment

The UAZ 2206 offers variable seat configurations. You can configure the number of seats exactly according to your needs. A safety box with tools, set of safety helmets and reflective vests are included. This vehicle is an ideal partner for technical assistance in hard terrain.

Technical Description

Vehicle
Make
UAZ
Type
2206
Business designation
UAZ Van 2206
Vehicle category
SG, expediční / SG, montážní
General construction characteristics
Number of axles
2
Number of wheels
4
Driving axles (number / position / connection)
2
Main dimensions
Wheelbase
2 300 mm
Length
4372-4876 mm
Width
1887-1950 mm
Height
2066-2380 mm
Weights
Mass of the vehicle in running order
1850-2475 kg
Technically permissible maximum masses

echnically permissible maximum laden mass
2880 kg
Technically permissible mass on axle 1
1 440 kg
Technically permissible mass on axle 2
1 440 kg
Technically permissible maximum mass of the combination
6 380 kg
Technically permissible maximum towable mass in case of

Centre-axle trailer
3500 kg
Unbraked trailer
750 kg
Technically permissible maximum static vertical mass at the coupling point
100 kg
Power plant
Manufacturer of the engine
Zavolzskyj motornyj zavod, Russia
Engine code as marked on the engine
409055
Number and arrangment of cylinders
4
Engine capacity
2693 cm3
Fuel
Petrol
Max. net power [kW] at [rpm]
83 / 4250
Maximum speed
Maximum speed
120 kph
Axles and suspension
Axle track 1
1 475 mm
Axle track 2
1 485 mm
Tyre/wheel combination (original design)
225/75 R16 108H/6,5Jx16
Body
Number and configuration of doors
4
Number of seating positions (including driver)
8
Coupling device
Approval number of drawbar approval marking (if installed)
A50-X
Enviromental performances
Sound level

Exhaust Emission level
EURO 6
